THE SUM OF AUDIO INNOVATION
The world’s first touchscreen marine stereo with the AirPlay® 2 software feature and built-in Wi-Fi® connectivity, Apollo RA770 has redefined audio excellence with revolutionary technology and innovative design.
Custom audio profiles for each zone on your boat to deliver superior quality audio.
Audio streaming with Wi-Fi technology provides high-quality audio with a faster data transfer rate.
Experience seamless high-quality audio streaming from your music app via the AirPlay® 2 software feature1.
Enjoy the freedom of musical choice with Fusion’s PartyBus™-Network technology1.
This 4.3-inch touchscreen includes play, pause and skip functions using touch display commands.
Control your music from a compatible multifunction display (MFD), smart device or Garmin watch.
General
| Water rating | IPX6 and IPX7 (front panel only, when properly installed) |
| Display | 4.3″ capacitive touchscreen colour LCD |
| Current (max) | 15 A |
Networking
| NMEA 2000® LEN | 1 (50 mA) |
| Bluetooth® wireless range | Up to 10 metres (30 ft) |
| ANT® wireless range | Up to 10 ft (3 metres) |
| Wireless frequencies/protocols | Wi-Fi®: 2.4 GHz @ +15 dBm nominal Bluetooth®: 2.4 GHz @ +10 dBm nominal ANT®: 2.4 GHz @ +4 dBm nominal |
AUDIO
| Amplifier | Class-D (2 Ohm stereo-stable) |
Electrical features
| POWER INPUT | 10.8 – 16 VDC |
| Compass safe distance | 5.9″ (150 mm) |
Stereo features
| Peak power | 280 watts |
| Rated power output (2 Ohm) | 43 watts RMS x 4 @ 14.4 V input < 10% THD |
| Rated power output (4 Ohm) | 26 watts RMS x 4 @ 14.4 V input < 10% THD |
| Built-in Wi-Fi® | ✔️ |
| Built-in Digital Signal Processing (DSP) | Yes (with custom DSP profile setup using Fusion-Link™ app) |
| Stereo networking | Yes (wired or wireless) |
| Control | Yes (MFD, smart device and Garmin watch) |
| Multi-Zone™️ technology | 4 zones |
| Bluetooth® wireless technology | ✔️ |
| ANT® wireless technology | ✔️ |
| SiriusXM-ready | ✔️ |
| DAB+ ready | ✔️ |
| Optical audio input | ✔️ |
| Supports ERX wired remote | ✔️ |
| Supports NRX wired remote | ✔️ |
| Multi-language interface | Bulgarian, Simplified chinese, Traditional chinese, Croatian, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (BR), Portuguese (PT), Slovenian, Spanish, Swedish, Thai, Turkish |
| Software updates | Over-the-air updates via Fusion-Link™ app / USB |
Sources
| Supported sources | AM, FM, Bluetooth®, Apple® AirPlay® 2, digital optical input, USB audio, iPhone®, iPod®, AUX x2, UPnP, MTP SiriusXM-Ready (U.S. only, requires optional SiriusXM Connect vehicle tuner) DAB+ ready (available in Europe and Australia only) |
Connections
| Auxiliary inputs (RCA) | 2 |
| Optical audio inputs (Digital Optical Input SPDIF) | 1 |
| Ethernet ports | 1 |
| NMEA 2000® ports | 1 |
| USB 2.0 ports | 1 |
| SiriusXM ports | 1 |
| Antenna ports | 1 |
| Speaker connections | 4 (2 zone amplified) |
| RCA Pre-out (left, right and subwoofer) | 4 zones (requires external amplification) |
| Line out | 4 (L + R per zone, requires external amplification) |
| Subwoofer out | 4 (1 mono output per zone, requires external amplification) |
In The Box
- Mounting gasket
- Four 8-gauge, self-tapping screws
- Two screw covers
- Power and speaker wiring harness
- Auxiliary-in, line-out, and subwoofer-out wiring harnesses
- 2 metre NMEA 2000® drop cable
- Dust cover
- Documentation
